Features:

Body

• Constructed of 22ga steel painted in black or white. The housing is supplied with a driver plate and safety cable that allow for a simple and secure installation.

LED Characteristics

• This general application light fixture features an LED module that maintains uniform intensity producing up to 1400 lumens per head; with a typical CRI of 94. On-fixture color selectable switch allows switching between 2700 K, 3000 K, 3500 K, 4000 K and 5000 K color temperatures.

Dimming

• 100%-1% dimming capability. This fixture is compatible with industry standard forward-phase / reverse-phase, TRIAC/ELV and 0-10V dimmers (contact factory for list of compatible dimmers).

Beam Spread

• 38° beam spread per head.

Mounting

• A universal mounting bracket is included to attach to any 4″ octagonal electrical box. The frame attached to the mounting bracket and secured with a set screw.
• NOTE: Support screws are required for 2- and 3-head options – see instructions.
