Liteline

DINE MONOPOINT

Price on demand

The DINE LED was specifically designed for restaurants and dining applications, allowing for ideal control of visual comfort. Low-glare lighting and flexibility to make on-site adjustments allows for perfect horizontal or vertical illumination for both high and low ceilings.

Body
Constructed of aluminum which provides superior strength and rigidity, the body features an aesthetically pleasing smooth cylindrical shape with dual finish color.
LED Characteristics
High powered 16W LED chip maintains uniform intensity with a typical luminous flux up to 900 lumens, with a typical CRI of 90+. Available in 3000 K color temperature.
Adjustability
Lamp housing is controlled with an adjustable link that provides 90° tilt and 330° rotation (for T and MP mounting options). Lamp holder bracket is height adjustable up to 2″.
Beam Spread
Beam spread dependent on attached standard Solite lens, honeycomb louver, snoot and the adjustable light source height (40° with 1″ snoot, 35° with 2″ snoot, 25° with 4″ snoot).
Dimming
Color temperature dimmable from 3000 K to 2000 K when used with industry standard forward-phase/ reverse-phase controls (contact factory for compatible dimmers).
Mounting Options
Multiple mounting options for various applications. Available mounting options include direct mounting onto a 4″ octagonal junction box for surface flushmount, surface pendant and monopoint applications, provided with one 7/8″ knockout with true pryout and ground wire for recessed pendant and recessed mount applications and 1- or 2-circuit track connectors for track applications (compatible with A-Line, 2- and 3-circuit Powergear, H-style, L-style and Liteline tracks). Includes two pressure spring loaded clips to attach to any ceiling material for RP and RF mounting options.
Compatibility
Available track connectors for compatibility with A-Line, Global ® , Halo ® , Liteline ® and Lightolier ® track systems.
Warranty
5-Year warranty.
